Table 17. Dimensions of the Dell PowerEdge R630 system
System Xa Xb Y Za (with
bezel)
Za
(without
bezel)
Zb Zc
Eight x 2.5-inch hard
drive systems
482.4 mm
(19 inches)
434.0 mm
(17.0 inches)
42.8 mm
(1.6 inches)
35.0 mm
(1.3 inches)
20.4 mm
(0.8 inches)
682.7 mm
(26.8
inches)
701.3 mm
(27.6
inches)
10 x 2.5-inch and 24
x 2.5-inch hard drive
systems
482.4 mm
(19 inches)
434.0 mm
(17.0 inches)
42.8 mm
(1.6 inches)
35.0 mm
(1.3 inches)
20.4 mm
(0.8 inches)
731.0 mm
(28.7
inches)
752.1 mm
(29.6
inches)
Chassis weight
Table 18. Chassis weight
System Maximum weight
Eight x 2.5-inch hard drive systems 16.9 kg (37.26 lb)
10 x 2.5-inch hard drive systems 18.5 kg (40.79 lb)
24 x 1.8-inch hard drive systems 17.4 kg (38.36 lb)
Processor specifications
The PowerEdge R630 system supports up to two Intel Xeon E5-2600 v3 or v4 product family processors.
PSU specifications
The PowerEdge R630 system supports up to two AC or DC redundant power supply units (PSUs).
Table 19. PSU specifications
PSU Class Heat dissipation
(maximum)
Frequency Voltage
495 W AC Platinum 1908 BTU/hr 50/60 Hz 100–240 V AC,
autoranging
750 W AC Platinum 2891 BTU/hr 50/60 Hz 100–240 V AC,
autoranging
750 W AC Titanium 2843 BTU/hr 50/60 Hz 200–240 V AC,
autoranging
1100 W AC Platinum 4100 BTU/hr 50/60 Hz 100–240 V AC,
autoranging
1100 W DC — 4416 BTU/hr — –(48–60) V DC
750 W DC (for China
only)
Platinum 2902 BTU/hr 50/60 Hz 100–240 V AC and 240
V DC
NOTE: Heat dissipation is calculated by using the PSU wattage rating.
NOTE: This system is also designed to connect to the IT power systems with a phase to phase voltage not exceeding 230
V.
Technical specifications 31
