Table 95. Configuration 3: R1C+R2+R4C (continued)
Card type Slot priority Maximum number of cards
Broadcom (NIC: 10 Gb) FH,4P,BT 1,2,7,8 4
Broadcom (NIC: 10 Gb) LP,4P,BT 3,6 2
Broadcom (NIC: 10 Gb) DP,57416,FH 1,2,7,8 4
Broadcom (NIC: 10 Gb) DP,57416,LP 3,6 2
Intel (NIC: 10 Gb) FH,4P,BT 1,2,7,8 4
Intel (NIC: 10 Gb) LP,4P,BT 3,6 2
Intel (NIC: 10 Gb) FH,2P,BT 1,2,7,8 4
Intel (NIC: 10 Gb) LP,2P,BT 3,6 2
Mellanox (NIC: HDR100 VPI)
CX6,SP,F,ML
1,2,7,8 4
Mellanox (NIC: HDR100 VPI)
CX6,SP,L,ML
3,6 2
Intel (NIC: 1 GB) QP,LP,F1 3,6 2
Intel (NIC: 1 GB) QP,F1 1,2,7,8 4
Broadcom (NIC: 1 GB) LP,4P,F1 3,6 2
Broadcom (NIC: 1 GB) FH,4P,F1 1,2,7,8 4
Broadcom (NIC: 25 GB) LP,2P,SFP,F1 3,6 2
Broadcom (NIC: 25 GB) FH,2P,SFP,F1 1,2,7,8 4
Marvell (HBA: FC32) FH,1P,S28,F1 1,2,7,8 4
Marvell (HBA: FC32) LP,1P,S28,F1 3,6 2
Emulex (HBA: FC32) LP,1P,SPDM 3,6 2
Emulex (HBA: FC32) FH,1P,SPDM 1,2,7,8 4
Marvell (HBA: FC32) FH,2P,S28,F1 1,2,7,8 4
Marvell (HBA: FC32) LP,2P,S28,F1 3,6 2
Emulex (HBA: FC32) LH,2P,SPDM 3,6 2
Emulex (HBA: FC32) FH,2P,SPDM 1,2,7,8 4
Emulex (HBA: FC64) FH,2P,SPDM 1,2,7,8 4
Emulex (HBA: FC64) LH,2P,SPDM 3,6 2
Removing the expansion card risers
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. Remove the air shroud.
4.
NOTE:
If BOSS-N1 module is installed, be sure to disconnect the BOSS-N1 power cable and Signal cable before
removing the Riser 1 cage.
CAUTION: To avoid damaging the power cable connector, press the latch on the BOSS-N1 power cable before
disconnecting.
132 Installing and removing system components
