Dell PowerEdge T130 - NIC indicator codes; Power indicator codes for power supply unit

NIC indicator codes
Figure 3. NIC indicators
1. link indicator 2. activity indicator
Table 4. NIC indicators
Convention Indicator pattern Description
A Link and activity indicators
are OFF
The NIC is not connected to the network.
B Link indicator is green The NIC is connected to a valid network at its maximum
port speed (1 Gbps).
C Link indicator is yellow The NIC is connected to a valid network at less than its
maximum port speed.
D Activity indicator is flashing
green
Network data is being sent or received.
Power indicator codes for power supply unit
Press the self-diagnostic button to perform a quick health check on the power supply unit (PSU) of the
system.
