Dell PowerEdge T620 - GPU Card Installation Guidelines

PCIe Slot Processor Connection Height Length Link Width Slot Width
3 Platform Controller Hub Standard Height Full Length* x4 x8
4 Processor 1 Standard Height Full Length x16 x16
5 Processor 2 Standard Height Full Length x16 x16
6 Processor 2 Standard Height Full Length x8 x8
7 Processor 2 Standard Height Full Length x16 x16
*PCIe Generation 2 expansion card.
NOTE
: To use PCIe slots 5, 6, and 7, both the processors must be installed.
NOTE
: The expansion-card slots are not hot-swappable.
The following table provides a guide for installing expansion cards to ensure proper cooling and mechanical fit. The
expansion cards with the highest priority must be installed first using the slot priority indicated. All other expansion
cards must be installed in card priority and slot priority order.
Table 4. Expansion Card Installation Order
Card Priority Card Type Slot Priority Maximum Allowed
1 Dell PowerEdge Express Flash
(PCIe SSD) Bridge
2 1
2 GPU (single width and double
width)
4, 5, 7, 2 4
3 External RAID 4, 5, 6, 2, 7, 1 6
4 Internal RAID 4, 2, 1, 3 4
5 Converged Network Adapters
(CNAs)
4, 5, 6, 2, 7, 1 6
6 10 Gb NICs 4, 5, 6, 2, 7, 1 6
7 FC4/8 HBA 4, 5, 6, 2, 7, 1, 3 7
8 1 Gb NICs 4, 5, 6, 2, 7, 1, 3 7
9 Non-RAID 1, 4, 5, 6, 2, 7 6
10 Internal SAS Tape 1,4,2 3
11 Non-RAID 1,4,5,6,2,7 6
12 Internal Tape Adapter 1,4,2 3
GPU Card Installation Guidelines
Observe the following guidelines while installing a GPU card:
• Ensure that the GPU enablement kit is ready.
• Ensure that all GPU cards are of the same type or model.
• Each GPU card supports up to 6 GB of dedicated GDDR5 memory.
• A single processor configuration only supports up to two double or single width cards on slots 2 and 4.
