Dell PowerEdge T630 - Installing the Optional Front Bezel

4. Remove the bezel by unhooking the bezel tabs from the slots at the bottom of the system.
5. Unhook the bezel tabs from the slots at the bottom of the system board, and pull the bezel away
from the system.
Figure 15. Removing the front bezel
1. bezel key
2. bezel
3. release latch 4. system
Related Links
Installing the optional front bezel
Installing the optional front bezel
1. Locate and remove the bezel keys.
NOTE: There are two bezel keys attached to the back of the bezel.
2. Insert the bezel tabs into the bezel tab slots in the chassis.
3. Press the release latch, and push the bezel toward the system until the bezel locks into place.
4. Lock the bezel by using the key.
76
