Management: Installing Array Components 241

16

Management: Installing Array

Components

Recommended Tools

You may need the following items to perform the procedures in this section:

• Key to the system keylock

•#2 Phillips screwdriver

•W

rist grounding stra

p

book.book Page 241 Friday, September 23, 2011 2:46 PM
