26 Specifications
ExpressCard
NOTE: The ExpressCard slot is designed only for ExpressCards. It does NOT support PC Cards.
NOTE: PCMCIA may not be available in some regions.
ExpressCard controller Intel ICH8M
ExpressCard connector one ExpressCard slot (54 mm)
Cards supported ExpressCard/34 (34 mm)
ExpressCard/54 (54 mm)
1.5 V and 3.3 V
ExpressCard connector size 26 pins
8-in-1 Memory Card Reader
8-in-1 memory card controller Ricoh R5C833
8-in-1 memory card connector 8-in-1 combo card connector
Cards supported
• Secure Digital (SD)
• Secure Digital Input/Output(SDIO)
• MultiMediaCard (MMC)
•Memory Stick
• Memory Stick PRO
• xD-Picture Card
•Hi Capacity-SD
• Hi Density-SD
Memory
Memory module connector two user-accessible SODIMM connectors
Memory module capacities 512 MB, 1 GB, and 2 GB
Memory type 667 MHz SODIMM DDR2
Minimum memory configuration 1 GB
Maximum memory configuration 4 GB
NOTE: In order to take advantage of the dual channel bandwidth capability, both
memory slots must be populated and must match in size.
NOTE: The available memory displayed does not reflect the complete maximum memory
installed because some memory is reserved for system files.
