Dell Precision M4600 Technical Specifications

Dell Precision M4600 Technical Specifications
Processors 2nd generation Intel® Core™ i5 and i7 processors, up to Core i7 Extreme Edition, with Intel vPro™ advanced
management; smart security and manageability on every chip.
Operating Systems • Genuine Windows
®
7 Ultimate (32-Bit or 64-Bit)
• Genuine Windows
®
7 Professional (32-Bit or 64-Bit)
• Genuine Windows Vista
®
Ultimate (32-Bit or 64-bit)
• Genuine Windows Vista
®
Business (32-Bit or 64-bit)
• Red Hat
®
Enterprise Linux
®
version 6 (select regions)
• Ubuntu Linux (select regions)
Chipset Mobile Intel
®
QM67 Express
Memory
3
4 DIMM slots: up to 32GB 1333MHz; Or up to 16GB 1600MHz memory
Graphics
2
• AMD FirePro M5950 Mobility Pro with 1GB GDDR5 dedicated memory
• NVIDIA Quadro 1000M with 2GB GDDR3 dedicated memory
• NVIDIA Quadro 2000M with 2GB GDDR3 dedicated memory
Display Options • 15.6" HD(1366x768): anti-glare, LED-backlit
• 15.6" HD(1366x768): multi-touch (supports stylus / four finger simultaneous touch), LED-backlit
• 15.6" FHD(1920x1080): UltraSharp™, wide view, anti-glare, LED-backlit, Premium Panel Guarantee
5
• 15.6" FHD(1920x1080): UltraSharp™ with PremierColor technology, IPS, wide view, anti-glare, LED-backlit,
Premium Panel Guarantee
5
Storage Options
6
Dell Fast Response Free Fall Sensor standard; Support for one 2.5" SATA drive:
• 7200rpm hard drive from 250GB up to 750GB; 7200rpm 320GB FIPS Certified Self Encrypting Drive
• Solid state drive (SSD) from 128GB to 256GB; 512GB coming soon
Optional 128GB Solid State Mini-Card secondary storage device
Optional RAID 0 or RAID 1 (when configured with 2.5" drive and solid state Mini-Card)
Communication Options Wired: Integrated 10/100/1000 Gigabit Ethernet
Wireless LAN and WiMax:
• Intel Centrino
®
Advanced -N + WiMAX 6250
• Intel Centrino
®
Ultimate-N 6300 3x3
• Dell Wireless 1501 (802.11 b/g/n 1x1)
Mobile Broadband & GPS:
• Dell Wireless™ DW5630 Multi-mode HSPA-EVDO Mini Card (Gobi™ 3000) with A-GPS
• Dell Wireless™ DW5550 Single-mode HSPA Mini Card with A-GPS
Bluetooth: Dell Wireless 375 Bluetooth
®
3.0
Multimedia • Dual integrated high quality speakers and dual integrated noise cancelling digital array microphones
• Optional, integrated, light sensitive HD video webcam with Dell Webcam Central software
Optical Storage Options DVD-ROM; Slot load DVD+/-RW; Blu-ray Disc™ writer
Standard I/O Ports
Left Rear Right
1 - Lock Slot 1 - VGA 2 - USB 3.0
2 - USB 2.0 1 - RJ-45 1 - DisplayPort
1 - IEEE 1394 1 - eSATA / USB 2.0 1 - Wireless switch
1 - Microphone 1 - HDMI
1 - Headphone
1 - 10-in-1 media card reader
1 - SmartCard reader
1 - 54mm ExpressCard slot
Chassis Materials: aluminum and magnesium alloy
Dimensions (HxWxD): 1.29"-1.44" x 14.80" x 10.08"; 32.7mm-36.8mm x 376mm x 256mm
Weight
7
: starts at 6.15lbs; 2.79kg
Power: 180W AC adapter
Slots: 1 full and 2 half Mini-Card slots
Battery Options 6-cell (60Wh) with ExpressCharge™; 9-cell (97Wh); 9-cell (87Wh) 3 Year Limited Hardware
8
Warranty battery
Input • Anti-microbial keyboard with number pad: standard or optional backlit
• Multi-touch touchpad with three buttons; track stick with three buttons
• Four finger multi-touch and stylus display option
Docking Options Port Replicators: E-Port Plus port replicator; Simple E-Port port replicator; E-Legacy Extender legacy port replicator
Stands: E-View Laptop Stand; E-Series Basic Monitor Stand; E-Series Flat Panel Monitor Stand
Security Lock slot; Trusted Platform Module 1.2 (TPM 1.2); Setup/BIOS Password; I/O Interface Security; Intel Anti-Theft
Protection option (iATP); Optional Contactless SmartCard reader; standard or FIPS certified fingerprint reader; Dell
ControlVault; FIPS certified hardware-based full disk encryption
Environmental
and Regulatory
Environmental standards (eco-labels) include: ENERGY STAR® 5.0, EPEAT Gold; China - RoHS, CECP, CEC; EU -
RoHS, WEEE; Germany - GS Mark; South Korea - RoHS, Eco-label; Japan - RoHS, Energy Law, Green PC
Other environmental options: Dell Energy Smart settings (select configurations); Dell Asset Recovery Service
Learn more at Dell.com/Precision
1
Subject to wireless provider’s broadband subscription and coverage area; additional charges apply.
2
GB means 1 billion bytes and TB equals 1 trillion bytes; significant system memory may be used to support graphics, depending on system memory size and other factors
3
A 64-bit operating system is required to support 4GB or more of system memory.
4
Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions
5
Dell UltraSharp(TM) monitors are backed with the Premium Panel Guarantee which will provide you with a replacement monitor should even one bright defective pixel be
found on the screen during the Limited Hardware Warranty
8
period.
6
GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
7
Weights vary depending on configuration and manufacturing variability.
8
For copy of Ltd Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see www.dell.com/warranty
Dell is a trademark of Dell Inc. ©2011 Dell Inc. All rights reserved.

Dell Precision M4600 Specifications

General

Bus type	DMI
Stepping	D2
Tjunction	100 C °C
Processor cache	6 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2700 Mobile Series
Processor socket	Socket 1224
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	2.2 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD capacity	320 GB
SSD capacity	128 GB
HDD interface	SATA II
SSD interface	SATA, SATA II
Storage media	HDD+SSD
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	448 GB
Number of HDDs installed	2
Display diagonal	15.6 \
Native aspect ratio	16:9
LightScribe	-
Security features	FIPS
Graphics card family	AMD
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
On-board graphics card ID	0x116
Discrete graphics card model	AMD FirePro M5950
On-board graphics card model	Intel® HD Graphics 3000
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Audio system	stereo
Pointing device	Touchpad
Keyboard language	German
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	3.0+HS
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
Password protection type	BIOS
Battery life (max)	- h
Number of battery cells	9
Certification	CECP, CEC, WEEE, GS Mark, Eco-label, Energy Law, Green PC
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Product color	Black
Housing material	Aluminum
AC adapter power	180 W
Processor code	SR00W
Processor ARK ID	50067
Processor package size	37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1224) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	256 mm
Width	376 mm
Weight	2790 g
Height (rear)	36.8 mm
Height (front)	32.7 mm
