Dell S2218H - Page 17

Operating Your Monitor | 17
Front Panel Button Description
1
Shortcut key/Preset Modes
Use this button to choose from a list of preset
modes.
Shortcut key/Volume
Use the buttons to adjust the volume. Minimum
is ‘0’ (-). Maximum is ‘100’ (+).
Menu
Use the MENU button to launch the On-Screen
Display (OSD) and select the OSD Menu. See
Accessing the OSD menu.
Exit
Use this button to go back to the main menu or
exit the OSD main menu.
2&3
Power On/Off button (with
LED indicator)
Use the Power button to turn the monitor On
and Off.
Solid white light indicates the monitor is On and
fully functional. Blinking white light indicates the
power save mode.
OSD controls
Use the buttons on the front of the monitor to adjust the image settings.
1
2
3
4
Front Panel Button Description
1
Up
Use the Up button to increase values or move up.
