65
Basic Specications
AC Adapter
Types 90 W
Input voltage 100–240 VAC
Input current
(maximum)
1.5 A
Input frequency 50–60 Hz
Output current 4.62 A (continuous)
Output power 90 W
Rated output voltage 19.5 VDC
Dimensions:
Height
Width
Length
16 mm (0.6 inches)
70 mm (2.8 inches)
147 mm (5.8 inches)
Weight (without AC power cord)
:
90 W 0.345 kg (0.76 lb)
AC Adapter
Temperature range
:
Operating 0° to 40°C (32° to
104°F)
Storage
–
40° to 70°C (–40° to
158°F)
Connector types
:
DC connector 3 pin, 7.4 mm plug
AC connector 2 pin - C7 (Japan
only)
3 pin - C5
Physical
Height 30 mm~43 mm
(1.18 in~1.69 in)
Width 392.6 mm (15.46 in)
Depth 288.6 mm (11.36 in)
