Replacing the Base Cover | 15
Replacing the Base Cover
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 9. After working inside your computer, follow the instructions in
"After Working Inside Your Computer" on page 11. For additional safety best
practices information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Procedure
1 Replace the battery-LED board. See "Replacing the Battery-LED Board" on page 21.
2 Slide the battery-LED-board cable into the battery-LED-board cable connector and
press down on the connector latch to secure the cable.
3 Carefully turn the base-cover assembly over and snap the base-cover assembly
into place.
4 Replace the screws that secure the base-cover assembly to the palm-rest assembly.
5 Replace the screws under the system badge that secure the base-cover assembly.
6 Slide the tabs on the system badge into the slots on the base-cover assembly and
snap the system badge into place.
