24 | Replacing the Speakers
Replacing the Speakers
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 9. After working inside your computer, follow the instructions in
"After Working Inside Your Computer" on page 11. For additional safety best
practices information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Procedure
1 Use the alignment posts on the palm-rest assembly to place the speakers in position.
NOTE: Ensure that the speakers are secured by the alignment posts.
2 Replace the screws that secure the speakers to the palm-rest assembly.
3 Adhere the mylar on the speakers.
4 Connect the speaker cable to the I/O-board connector.
5 Adhere the tape that secures the speaker cable to the battery.
Postrequisites
1 Follow the instructions from step 2 to step 6 in "Removing the Base Cover" on
page 12.
