20 | Replacing the Memory Module(s)
3 Insert the memory module into the memory-module connector until the memory
module snaps into position.
If you insert the memory module correctly, the securing clips snap into the cutouts
at each end of the memory module.
Postrequisites
1 Replace the graphics card. See "Replacing the Graphics Card" on page 29.
2 Replace the computer cover. See "Replacing the Computer Cover" on page 16.
1 securing clip (snapped in position) 2 memory-module connector
3memory module
1
2
3
