Replacing the primary hard-drive
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
CAUTION: Hard drives are fragile. Exercise care when handling the hard
drive.
GUID-72A6FE31-4285-491F-A242-8E71FDEAAD14
Procedure (with tabs)
1 Place the hard drive into the hard-drive carrier and align the tabs on the bracket
with the slots on the hard drive.
2 Snap the hard-drive carrier into the hard drive.
3 Slide the hard-drive carrier into the hard-drive cage until it snaps into place.
4 Connect the data and power cables to the hard-drive.
GUID-D64D31F4-66C5-46A8-A059-0B0B3626DF49
Post-requisites
Replace the right-side cover.
37
