Speakers: Dell XPS M1710 Service Manual
file:///C|/Users/santhosh_v.ASIA-PACIFIC/Desktop/Hawke/New%20folder/speakers.htm[2/21/2014 11:23:57 AM]
4 speakers (2) 5 speaker cables (2) 6 connectors on system board (2)
Replacing the Speakers
1. Connect the speaker cable connectors to the connectors on the system board.
2. Align the speakers on the screw holes for securing the speakers to the computer base.
3. Replace the four M2.5 x 5-mm screws to secure the speakers in place (two on each speaker).
4. Re-route the speaker cables into the cable guides, and re-adhere the tape to secure the speaker cables in place on the
computer base.
