DeLonghi DD Series - Description of Appliance; Appliance Components

Description of Appliance
The following terms are used throughout the instruction manual
1
3
7
2
4
4
5
8
11
10
9
6
2
DEHUMIDIFIER DD Series
DESCRIPTION/ACCESSORIES
1. Control panel
2. Water level viewing window
3. Condensate collection tank
4. Handles
5. Air intake grille
6. Dust filter
7. Air outlet grille
8. Drain hose to be used at the back of the unit
9. Pump tube to be used at the front of the unit
10. Connector for PUMP draining (first remove stopper)
11. Wheels
