3
For 2003-2006 Denali and Escalade EXT & ESV & ASP Conversion
Remove the 30 amp fuse from the under hood electrical center.
The fuse is located in the bottom right corner of the box if you are standing on the driver’s
side of the vehicle looking toward the engine (see picture).
You can also look on the under side of the lid for location diagram.
Disconnect the Battery Negative Cable. WARNING: If you don’t, the vehicle could accidentally
start and move during this procedure and result in serious personal injury, including death.
Make sure the parking brake is engaged.
Remove Dash Bezel - Gently Snaps Off.
Tilt the steering wheel down and put the gear selector into 1st with the engine off.
With your fingers, start from the top right corner (corner above the radio - see picture) and
gently pull out
Continue around the top of the bezel and work to the sides and bottom.
NOTICE: Be careful when removing the bezel over the Emergency Light Switch located on top of the
steering column. This can scratch the bezel very easily.
Put gear selector back into Park.
1.
•
•
2.
3.
4.
•
•
•
•
Radio/Amp
Fuse
To Next Page
