STEP 4
PASO 4
Parts and tools required to complete step
Piezas y herramientas necesarias para completar este paso
BB
CC
50mm Bolt x5
Perno 50mm
Crescent Washer x5
Arandela de Media Luna
M4 Ball End Screwdriver
M4 destornillador hexagonal
M4 Allen Wrench
Llave Allen
Attach Right Side (Part B) to
the case assembly from Step
#3 using (5) 50mm Bolts (Part
BB) and (5) Crescent Washers
(Part CC). Carefully align all
dowels and holes, then install
the Bolts and Crescent Wash-
ers with the Ball End Screw-
driver and the Allen Wrench
following the instructions on
page 14 and 15.
Fijar el lado derecho (pieza B) a lo ya
ensamblado en el paso # 3 utilizando
(5) pernos de 50 mm (pieza BB) y (5)
arandelas de media luna (pieza CC).
Alinear con cuidado todos los pasa-
dores con los agujeros, instalar luego
los pernos y las arandelas de media
luna utilizando el destornillador hexag-
onal y la llave Allen siguiendo las
instrucciones de las páginas 14 y 15.
