24
STEP 5
PASO 5
Parts and tools required to complete step
Piezas y herramientas necesarias para completar este paso
BB
50mm Bolt x8
Perno 50mm
FF
M8 x 30mm Wood Dowel x4
Pasador de Madera M8 x 30mm
M4 Ball End Screwdriver
M4 destornillador hexagonal
M4 Allen Wrench
Llave Allen
Insert (4) M8 x 30mm Wood
Dowels (Part FF) into the Left Side
(Part A) and Right Side (Part B).
Carefully align all dowels with the
holes in the Top (Part J). Attach
the Top (Part J) using (8) 50mm
Bolts (Part BB). Tighten the bolts
using the Ball End Screwdriver,
then ensure the bolts are tight
using the Allen Wrench like
shown on page 15.
Insertar (4) pasadores de madera M8
x 30mm (pieza FF) en el lado izquierdo
(pieza A) y en el lado derecho (pieza
B). Alinear con cuidado todos los
pasadores con los agujeros del panel
superior (pieza J). Fijar el panel
superior (pieza J) utilizando (8)
pernos de 50mm (pieza BB). Apretar
los pernos utilizando el destornillador
hexagonal. Asegurarse de que todos
los pernos estén apretados utilizando
la llave Allen como se muestra en la
página 15.
