Delta Children Bookcase - Hardware System Guide; Pre-Assembly Review and Steps

8
N
K
50mm Bolt
Perno 50mm
1. Insert the Dowels in the Rail into the holes
in the Post.
1. Inserte los pasadores del Riel en los
agujeros del Poste.
Hardware System - Review Before Assembly
Revise Antes De Armar- Elementos De Fijacion Y Ensamble
Crescent Washer
Arandela de Media Luna
2. Slide the Crescent Washer into the slot,
over the hole.
2. Deslice la arandela de media luna en la
ranura, sobre el orificio.
3. Install the bolt through the crescent
washer and tighten as shown.
3. Instale el perno a través de la arandela
de media luna y apriete como se muestra.
