English-8
MODEL DOP-B07S200
COM1 RS-232
COM2 RS-232/422/485
Serial
COM Port
COM3 RS-232/422/485
Function Key User defined key x 4 + System key x 4
Perpetual Calendar (RTC) Built-in
Cooling Method Natural air circulation
Safety Approval
(Waterproof for front panel)
IP65 / NEMA4 / CE, UL
Operation Voltage DC +24V (-10% ~ +15%) (Users please use isolated power supply.)
Consumption Power 7.5W
Backup Battery 3V lithium battery CR2032 x 1
Backup Battery Life
It depends on the temperature used and the conditions of usage,
about 3 years or more at 25
o
C.
Operation Temp. 0°C ~ 50°C
Storage Temp. -20°C ~ +60°C
Ambient Humidity
10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
Pollution Degree 2
Vibration Resistance
IEC 61131-2 Compliant
5Hz≦f＜9Hz = Continuous: 1.75mm / Occasional: 3.5mm
9Hz≦f≦150Hz = Continuous: 0.5g / Occasional: 1.0g
X, Y, Z directions for 10 times
Dimensions
(W) x (H) x (D) mm
215 x 161 x 50
Panel Cutout
(W) x (H) mm
196.9 x 142.9
Weight Approx. 800g
NOTE
1) Users can download the Screen Editor, the program editor of Delta HMI product and the user manual via the
following link: http://www.delta.com.tw/industrialautomation/
.
