Delta Temperature Controller User Manual
2007-09-17 - 18 - © DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
Display Explanations
PV SV Status of the temperature controller
ON/OFF of auto-tuning
The 0
th
PID parameter. There are 4 groups of PID parameters
built in DTB. When the parameter is set ass PID4, the system
will automatically adopt the PID value of the current temperature
closest to PID0 ~ 3.
The 0
th
SV
The 0
th
default value for proportional control
The 0
th
default value for integral control
The 0
th
default value for derivative control
The 0
th
default integral value
Heating/cooling control cycle
Temperature inaccuracy adjustment value
Press in the main screen of DTB to enter the “operation mode”.
Display Explanations
PV SV Status of the temperature controller
Run/stop
Set up the position of decimal point
Key-locked function
Output volume. In PID control mode, this is a read-only
parameter and cannot be modified.
