Appendix A List of Devices|DOP-EXIO Series
Revision March, 2008, Doc. Name: 2007PDD23000014 A-3
Special
M
Function
Power Off
Ø
Power On
STOP
Ø
RUN
RUN
Ø
STOP
Attribute Latched Default Applicable Model
M1068 Calculation error locked Off - - R No Off
M1161
8/16 bit mode switch
On: in 8-bit mode
Off - - R/W No Off
DOP-EXIO14RAE
DOP-EXIO28RAE
*1: M1000 (A contact) is constantly “On” during operation and detection. When ELC is in RUN status, M1000 remains “On”.
*2: M1001 (B contact) is constantly “Off” during operation and detection. When ELC is in RUN status, M1001 remains “Off”
*3: M1002 is “On” during the first scan when ELC starts to RUN and remains “Off” afterward. The pulse width = 1 scan time. Use this contact
for all kinds of initial settings. (On immediately when RUN).
*4: M1003 is “Off” during the first scan when ELC starts to RUN and remains “On” afterward. M1003 enables negative-direction pulses. (“Off”
immediately when RUN)
