Appendix B List of Instructions|DOP-EXIO Series
B-2
Revision March, 2008, Doc. Name: 2007PDD23000014
Available Instructions
16-bit Instruction 32-bit Instruction Function
SUM DSUM Sum of Active Bits
BON DBON Check Specified Bit Status
MEAN DMEAN Mean
REF - Refresh
ALT - Alternate State
ASCI - Convert Hex to ASCII
AND= DAND= Series Connection Contact Compare =
AND> DAND> Series Connection Contact Compare >
AND< DAND< Series Connection Contact Compare <
AND<> DAND<> Series Connection Contact Compare <>
AND<= DAND<= Series Connection Contact Compare <=
AND>= DAND>= Series Connection Contact Compare >=
MPP - Pop (recall and remove) the currently stored result
OUT - Output Coil
SET -
Latch（ON）
RST - Clear the contacts or the registers
TMR - 16-bit Timer
CNT DCNT 16-bit / 32-bit Counter
MC - Master Control Start
MCR - Master Control Reset
LDP - Rising-edge Detection Operation
LDF - Falling-edge Detection Operation
STL - Step Transition Ladder Start Command
RET - Step Transition Ladder Return Command
CJ - Conditional Jump
CALL - Call Subroutine
SRET - Subroutine Return
FEND - The End of the Main Program (First End)
FOR - Start of a FOR-NEXT Loop
NEXT - End of a FOR-NEXT Loop
CMP DCMP Compare
ZCP DZCP Zone Compare
DIV DDIV Division
INC DINC Increment
DEC DDEC Decrement
WAND DAND Logical Word AND
WOR DOR Logical Word OR
