DELTA MCS 1800 3U Power Shelf
Installation, Operations and
Maintenance Manual
REV: 00 A-17
Figure 3-4 ES 48/90-JFAxx (DC Output Lug Distribution)
LOAD -48V TERMINAL
(USE 1015 4AWG~8AWG)
BATT+0V TERMINAL
(USE 1015 4AWG~8AWG)
LOAD +0V TERMINAL
(USE 1015 4AWG~8AWG)
BATT. -48V TERMINAL
(USE 1015 4AWG~8AWG)
