繁中-7
各部位說明
DOP-B05S100（正面）
A
電源指示燈（綠燈亮：正常運作）
B
操作／顯示區域
DOP-B05S100（背面）
A
電源輸入端子
E USB Host
B
COM2（RS-232／RS-422／RS-485）
F USB Client
C
COM1（RS232）
G
系統鍵
D
電池外蓋
A
B
D
C
B
A
E
F
G
