繁中-10
DOP-B07S200／DOP-B07S201／DOP-B07S211／DOP-B07E205／DOP-B07E215（背面）
A
電源輸入端子
F
網路埠（LAN）
B
COM3（RS-232／RS-422／RS-485）（支援通訊
狀態指示燈號）
G USB Host
C
COM2（RS-232／RS-422／RS-485）（支援通訊
狀態指示燈號）
H
音效輸出埠
D
COM1（RS232）
I
電池／記憶卡外蓋
E USB Client - -
G
D
C
B
A
I
E
F
H
