简中-10
DOP-B07S200／DOP-B07S201／DOP-B07S211／DOP-B07E205／DOP-B07E215（背面）
A 电源输入端子 F 网络端口（LAN）
B
COM3（RS-232／RS-422／RS-485）（支持通讯
状态指示灯号）
G USB Host
C
COM2（RS-232／RS-422／RS-485）（支持通讯
状态指示灯号）
H 音效输出端口
D COM1（RS232） I 电池／记忆卡外盖
E USB Client - -
G
D
C
B
A
I
E
F
H
