MON1,
MON2
Setting
Value
Description
0
Motor speed (+/-8 Volts/Max. speed)
1
Motor torque (+/-8 Volts/Max. torque)
2
Pulse command frequency (+8 Volts／4.5Mpps)
3
Speed command (+/-8 Volts/Max. speed command)
4
Torque command (+/-8 Volts/Max. torque
command)
5
VBUS voltage (+/-8 Volts／450V)
6
Reserved
7
Reserved
MON1 axis
selection
Description
1
MON1 is from X axis
2
MON1 is from Y axis
3
MON1 is from Z axis
MON2 axis
selection
Description
1
MON2 is from X axis
2
MON2 is from Y axis
3
MON2 is from Y axis
NOTE
Please refer to parameter P1-04, P1-05 for proportional setting
of analog output voltage.
For example: P0-03 = 1101 (MON1 is the analog output of
motor speed in X axis; MON2 is
the analog output of motor torque
in X axis.)
MON1outputvoltage  8 

󰇛.


󰇜
(unit: Volts)
MON2output voltage  8 

󰇛.  


󰇜
(unit: Volts)
P0-04■
Reserved
Address: 0008H
0009H
