As shown in Figure 4, depending on the size of the bike and the wheel, both the height of the tray and the
size of the tray will change.
ADJUSTING WHEEL TRAY SIZE AND HEIGHT
FOR DIFFERENT BIKES
FIGURE 5
FIGURE 4
Service: Please do not return to store;
for immediate response email
service@designbydelta.com
Delta Cycle Corporation
36 York Avenue, Randolph, MA 02368 USA
800-474-6615 / www.designbydelta.com
© Copyright 2022
011923
1
2
The wheel tray length should be adjusted so that the wheel sits as deep into the tray as it can without
the tray coming in contact with the frame or fork. (Figure 5)
The height of the tray should be adjusted so that the rear wheel of the bike is barley o the ground level
and that the tire is contacting the wheel stop on the base piece.
