31.
Byte
0
1
2
3
4
5
6
7
8
9
10
11
IP
0x90
Status1
Status2
Warning
Alarm
Voltage(V)
Current(.0A)
Power(.0Kw)
Byte
12
13
14
15
16
17
18
19
20
21
22
23
User
Command
Arc Counter(/s)
Arc Counter
0x00
Check
Sum
0x00
0x0D
Note: Check Sum Value is the summation of “1” signal calculated by byte 0 to 6.
Note: Use 9600bps, 8 data bits, no parity, 1 stop bit (9600 8-N-1)
Bit
0
1
2
3
4
5
6
7
Status1
CV
MODE
CC
MODE
CP
MODE
HV ON
Setpoint
MODE
Ignition
MODE
System
Warning
System
Shutdown
Bit
0
1
2
3
4
5
6
7
Status2
System
Ready
OVP
OCP
OTP
OPP
Interlock
Arc
Protect
AC Bus
Protect
Table 6.5 Value definition (Translate decimal to hexadecimal for utilizing)
Command
Byte3
Byte4
Byte5
Byte6
CV Mode
0 to 1000 for 0 to 1000V
CC Mode
0 to 462 for 0~4.62A
CP Mode
20 to 1500 for 10w to 1500W
A/Ri Offset
Plus: 00, Minus: 01
0 to 99 for 0 to 9.9%
A/Vo Offset
Plus: 00, Minus: 01
0 to 99 for 0 to 9.9%
A/Io Offset
Plus: 00, Minus: 01
0 to 99 for 0 to 9.9%
Set Point
1 to 10 for 1 to 10s
pause Time
2 to 100 for 200 to 10000us, Scale: 100us
Pulse frequency
0 to 80 for DC to 400k Scale:5kHz
Pulse reverse time
4 to 100 for 0.4us to 10us Scale:0.1us
Energy Mode
1 to 99999 for 1 to 99999kJ, 0: OFF
Arc Function
OFF: 0, ON: 1
Max Power
20 to 1500 for 20 to 1500W
Max Current
10 to 462 for 0.01 to 4.62A
Max Voltage
325 to 1000 for 325 to 1000V
Ramp Time
5 to 200 for 50 to 2000ms
Target Life
0 to 9999kWh for OFF to 9999kWh, 0: OFF
Arc Voltage
10 to 250 for 10 to 250
Arc Density
0 to 99 for 0 to 99 times/s
Arc Number
0 to 999 for 0 to 999 times
Ignition
10 to 19 for 1000V to 1900V
Note: Please use hexadecimal
