Chapter 3 Software Operation
LD-E Operation Manual
◎ Communication setting operation area
Connection settings
Connect after setting up according to the communication format
Scanning
Step1: Set up the port
Step2: Select RTU/ASCII mode
Step3:
Select the station number range
Step4: Start scanning
◎ Information area
After scanning, the information of each LD on the same BUS will be displayed in the information area,
up to 8 units.
Note: The station number needs to be different.
Connection settings
Scanning
