The PICOSTATION-M2-HP is probably the smallest and the most powerful Access Point on the market - maximal
output power is up to 1000 mW.
The SMA-RP socket allows to connect an additional external antenna. The kit includes power supply unit with
PoE adapter.
Frequency range: 2412 MHz ... 2462 MHz
Antenna type: 6 dBi Omnidirectional antenna
Standards:
• IEEE 802.11b,
• IEEE 802.11g,
• IEEE 802.11n,
• IEEE 802.3af,
• IEEE 802.11e
Ethernet interface: 10/100 Mbps BASE-TX (Cat. 5, RJ-45)
Receiver sensitivity:
• -97 dBm @ 1 ... 24 Mbps
• -80 dBm @ 36 Mbps
• -77 dBm @ 48 Mbps
• -75 dBm @ 54 Mbps
Operating system: AirOS
Operation mode: Station, Station WDS, Access Point, Access Point WDS
Transmitter power:
• 28 dBm @ 1 ... 24 Mbps
• 27 dBm @ 36 Mbps
• 26 dBm @ 48 Mbps
• 24 dBm @ 54 Mbps
Memory: 32 MB SDRAM, 8 MB FLASH
Processor: Atheros MIPS 24KC, 400MHz
Power supply PoE:
Power supply: 15 V / 0.8 A (power adapter included)
