PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT.

V. BARREL NUT x 26

X. Φ8x40 mm WOOD DOWEL x 4

M4 ALLEN WRENCH SUPPLIED

Y. PLATE x 2

R. M6x90 mm BOLT x 4

U. M6x45 mm BOLT x 2

T. M6x63 mm BOLT x 14

S. M6x76 mm BOLT x 11

W. Φ4.5x30 mm METAL PIN x 2
