Chapter 11 Summary of Parameter SettingsC2000-HS
11-23
05 Motor Parameters
Pr. Parameter Name Setting Range Default
05-00 Motor parameter auto-tuning
0: No function
1: Simple rolling auto-tuning for induction motor (IM)
2: Static auto-tuning for induction motor (IM)
4: Dynamic test for PM magnetic pole
(with the running in forward direction)
5: Rolling auto-tuning for PM
6: Advanced rolling auto-tuning for IM flux curve
12: FOC sensorless inertia estimation
13: Static auto-tuning for PM
0
05-01
Full-load current for induction
motor 1 (A)
Depending on the model power
Depending
on the
model
power

05-02
Rated power for induction motor
1 (kW)
0.00–655.35 kW
Depending
on the
model
power

05-03
Rated speed for induction motor
1 (rpm)
0–xxxx (Depending on the motor pole number)
Depending
on the
motor pole
number
05-04
Number of poles for induction
motor 1
2–64 4
05-05
No-load current for induction
motor 1 (A)
0.00–Pr. 05-01 default
Depending
on the
model
power
05-06
Stator resistance (Rs) for
induction motor 1
0.000–65.535 
Depending
on the
model
power
05-07
Rotor resistance (Rr) for
induction motor 1
0.000–65.535 
0.000
05-08
Magnetizing inductance (Lm) for
induction motor 1
0.0–6553.5 mH 0.0
05-09
Stator inductance (Lx) for
induction motor 1
0.0–6553.5 mH 0.0
05-13
Full-load current for induction
motor 2 (A)
Depending on the model power
Depending
on the
model
power

05-14
Rated power for induction motor
2 (kW)
0.00–655.35 kW
Depending
on the
model
power

05-15
Rated speed for induction motor
2 (rpm)
0–xxxx (Depending on the motor pole number)
Depending
on the
motor pole
number
05-16
Number of poles for induction
motor 2
2–64 4
05-17
No-load current for induction
motor 2 (A)
0.00–Pr. 05-13 default
Depending
on the
model
power
