15
3. FRONT WHEEL &
FRONT BRAKE
YOUR BIKE HAS A BOLT ON MECHANISM
1. Remove Packing Block from disc
brake caliper – Do Not Throw Away –
Re-install Packing Block whenever
you remove your front wheel.
2. Position the front wheel so it’s
centered between the front fork legs
with the axle resting inside the fork
drop outs.
3. Align the disc brake rotor so it is
centered in the slot of the brake caliper.
4. Tighten one axle nut part way then tighten
the other nut, repeat until both sides are
tightened securely. Be sure that the
wheel is centered between the fork legs.
CAUTION
Tighten nuts securely to the fork dropouts
To Next Page
