29
UNINSTALLING THE BATTERY
1 2 3
1. Turn Key Until you hear CLICK
2. Move latch holder at top of battery
and pull top of battery away from the frame.
3. Lifting battery out
4. Frame area is clear of battery. Check connectors
toward the bottom of battery cavity
3. Battery should be inside cavity and press closed
to hear a click
4. Key is not needed to install battery but if in place
remove and Enjoy the Ride
1. With Open Battery Cavity, check connectors.
Key is not needed to install battery
2. Place bottom of battery into frame cavity
and slide down to connect
REINSTALLING THE BATTERY
E18
