Denon AVC-1890

14
AVR-2105/885 / AVC-1890
87 OVERLOAD I OVERLOAD DETECT
88 VSS - VSS
89 VDD(BACK UP) - VDD FOR BACK UP
90 NC - -
91 TC94A27UG_STB - TC94A27UG CONTROL
92 TC94A27UG_PLL_DATA O PLL CONTROL (LC72131),DATA (TC94A27UG)
93 TC94A27UG_PLL_CLK O PLL CONTROL (LC72131),CLOCK (TC94A27UG)
94 PLL_DT_IN I PLL CONTROL (LC72131)
95 TU_MUTE O TUNER MUTE
96 ST I STEREO DETECT
97 TUNED I TUNE DETECT
98 PLL_CE O PLL CONTROL (LC72131)
99 2090_CLK1 O BU2090 CLOCK(VIDEO)
100 2090_74781_DATA O BU2090/LC74781 CONTROL DATA(VIDEO)
PIN
No.
PIN NAME I/O FUNCTION
