Denon AVC-1890

44
AVR-2105/885 / AVC-1890
CP106 00D 960 0123 207 3P connector base
CP1151 00D 963 0097 507 15P connector base (TUC-P)
CP1153 00D 963 0097 507 15P connector base (TUC-P)
CP138A 00D 960 0123 207 3P connector base
CP3911 00D 963 0160 900 8P connector base *
CP392 00D 963 0048 909 3P connector base
CP501 00D 963 0086 806 9P connector base (TUC-P)
CP502 00D 963 0085 807 7P connector base (TUC-P)
CP503 00D 963 0085 807 7P connector base (TUC-P)
CP504 00D 963 0086 903 5P connector base (TUC-P)
CP505 00D 963 0087 708 12P connector base (TUC-P)
CP555 00D 963 0111 108 14P connector base (TUC-P)
CP556 00D 963 0087 805 11P connector base (TUC-P)
CP901 00D 963 0048 909 3P connector base
CP931 00D 963 0149 206 2P connector base(BLUE)
! F102 00D 960 0188 705 Fuse 8A
F102A 00D 960 0005 804 Fuse clip
F102B 00D 960 0005 804 Fuse clip
GND101 00D 960 9006 600 Terminal
GND102 00D 960 9006 600 Terminal
GND103 00D 960 9006 600 Terminal
JK901 00D 963 0095 402 Head phone jack
L101C 00D 963 0049 005 Inductor 0.5uH
L101FL 00D 963 0049 005 Inductor 0.5uH
L101FR 00D 963 0049 005 Inductor 0.5uH
L101SL 00D 963 0049 005 Inductor 0.5uH
L101SR 00D 963 0049 005 Inductor 0.5uH
RLY101 00D 960 0181 702 Relay (G5PA-28 24V)
RLY102 00D 960 0181 702 Relay (G5PA-28 24V)
RLY103 00D 960 0181 702 Relay (G5PA-28 24V)
RLY104 00D 960 0181 702 Relay (G5PA-28 24V)
RLY105 00D 963 0071 303 Relay (RSB24S 24V)
! RLY106 00D 960 0181 605 Relay (G5PA-1-8 12V)
RLY107 00D 960 0181 702 Relay (G5PA-28 24V)
SW391 00D 963 0045 708 Tact switch
SW393 00D 963 0045 708 Tact switch
SW901 00D 963 0045 708 Tact switch
SW901A 00D 963 0145 802 Push switch
TP101 00D 960 0161 405 3P connector base
TP102 00D 960 0161 405 3P connector base
TP103 00D 960 0161 405 3P connector base
TP104 00D 960 0161 405 3P connector base
TP105 00D 960 0161 405 3P connector base
VEC303 00D 963 0095 208 ENCODER SW
- - Heat sink 1
- - Heat sink 1
! - 00D 963 0094 924 Power trans. (Mini) 1
- 00D 963 0018 007 Screw (2S 3Å~8 ZNY/BH) 3
- 00D 963 0158 608 2P speaker terminal 1 *
- 00D 963 0119 906 8P speaker terminal 2
Ref. No. Part No. Part Name Remarks New
