Denon AVR-2803 Service Manual

77
77
AVR-2803/983/AVC-2870
CX093 205 0233 090 9P EH CONNECTOR BASE
CX111 205 0884 067 11P CON.BASE TUC-P
CX113 205 0884 067 11P CON.BASE TUC-P
CX116 205 1091 024 11P CON BASE TWG-P
CX153 205 0884 041 15P CON.BASE TUC-P
CX193 205 1091 008 19P CON.BASE(TWG-P)
! F1 206 1086 003 FUSE 8A (UL/CSA/J) *
! F8 206 1052 008 FUSE 8A
! F11-15 206 1035 009 FUSE 3.15A (T)
FF500 202 0057 905 FUSE CLIP (TAPE)
FF502 202 0040 909 FUSE CLIP (TAPE)
FF601-605 202 0040 909 FUSE CLIP (TAPE)
FH501 202 0057 905 FUSE CLIP (TAPE)
FH502 202 0040 909 FUSE CLIP (TAPE)
FH601-605 202 0040 909 FUSE CLIP (TAPE)
! RL502 214 0221 006 RELAY TV-8
ST601 205 1034 010 M3 SCREW TERMINAL
415 0299 000 CONDENSER COVER for C525
415 0309 026 P.V.C. TUBE(L=20) for PT601
513 2585 045 FUSE LABEL
513 2585 061 FUSE LABEL
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
