Denon AVR-5308CI - CHECK WITH TEST MODE

26
AVR-5308CI / AVC-A1HD
CHECK WITH TEST MODE
µcom/DSP Error Display Mode
1. Operation Spec
µcom version display mode:
When the following conditions are satisfied at its starting state, error information is displayed before version information.
Starting method (same as µcom version display):
While pressing 2 buttons, "STATUS " and "MONITOR SELECT ", turn on Power switch.
Then, press "STATUS" button to display the following information on the FL Display.
2. Display Order
Error information →Destination information →Main-µcom version information → Sub-µcom version information
→ DSP version information
3. Display
Any one of the following list is displayed, in the priority of qwerty..
Condition State Display
q
Sub-µcom NG
No response from Sub-µcom
" □ ＳＵＢ □□ ＥＲＲＯＲ □０１□ "
w DIR NG
No response from DIR
" □ ＤＩＲ □□ ＥＲＲＯＲ □０１□ "
e DSP1 NG
When DSP boot, executing DSP reset makes no change to BUSY port "L".
"□ＤＳＰ1 □ ＥＲＲＯＲ □０１□ "
No change to BUSY port "L" before issuing DSP command.
"□ＤＳＰ1 □ ＥＲＲＯＲ □０２□ "
When DSP data read, executing WRITE="L" makes no change to ACK="H".
"□ＤＳＰ1 □ ＥＲＲＯＲ □０３□ "
When DSP data read, executing REQ="L" makes no change to ACK="L".
"□ＤＳＰ1 □ ＥＲＲＯＲ □０４□ "
When DSP data write, executing WRITE="H" makes no change to ACK="H".
"□ＤＳＰ1 □ ＥＲＲＯＲ □０５□ "
When DSP data write, executing REQ="L" makes no change to ACK="L".
"□ＤＳＰ1 □ ＥＲＲＯＲ □０６□ "
When DSP special code boot, executing DSP reset makes no change to
BUSY port "L".
"□ＤＳＰ1 □ ＥＲＲＯＲ □１１□ "
No change to BUSY port "L" before issuing DSP special read command.
"□ＤＳＰ1 □ ＥＲＲＯＲ □１２□ "
No change to BUSY port "L" before DSP version read.
"□ＤＳＰ1 □ ＥＲＲＯＲ □１３□ "
r DSP2 NG
When DSP boot, executing DSP reset makes no change to BUSY port "L".
"□ＤＳＰ2 □ ＥＲＲＯＲ □０１□ "
No change to BUSY port "L" before issuing DSP command.
"□ＤＳＰ2 □ ＥＲＲＯＲ □０２□ "
When DSP data read, executing WRITE="L" makes no change to ACK="H".
"□ＤＳＰ2 □ ＥＲＲＯＲ □０３□ "
When DSP data read, executing REQ="L" makes no change to ACK="L".
"□ＤＳＰ2 □ ＥＲＲＯＲ □０４□ "
When DSP data write, executing WRITE="H" makes no change to ACK="H".
"□ＤＳＰ2 □ ＥＲＲＯＲ □０５□ "
When DSP data write, executing REQ="L" makes no change to ACK="L".
"□ＤＳＰ2 □ ＥＲＲＯＲ □０６□ "
When DSP special code boot, executing DSP reset makes no change to
BUSY port "L".
"□ＤＳＰ2 □ ＥＲＲＯＲ □１１□ "
No change to BUSY port "L" before issuing DSP special read command.
"□ＤＳＰ2 □ ＥＲＲＯＲ □１２□ "
No change to BUSY port "L" before DSP version read.
"□ＤＳＰ2 □ ＥＲＲＯＲ □１３□ "
t DSP3 NG
When DSP boot, executing DSP reset makes no change to BUSY port "L".
"□ＤＳＰ3 □ ＥＲＲＯＲ □０１□ "
No change to BUSY port "L" before issuing DSP command.
"□ＤＳＰ3 □ ＥＲＲＯＲ □０２□ "
When DSP data read, executing WRITE="L" makes no change to ACK="H".
"□ＤＳＰ3 □ ＥＲＲＯＲ □０３□ "
When DSP data read, executing REQ="L" makes no change to ACK="L".
"□ＤＳＰ3 □ ＥＲＲＯＲ □０４□ "
When DSP data write, executing WRITE="H" makes no change to ACK="H".
"□ＤＳＰ3 □ ＥＲＲＯＲ □０５□ "
When DSP data write, executing REQ="L" makes no change to ACK="L".
"□ＤＳＰ3 □ ＥＲＲＯＲ □０６□ "
When DSP special code boot, executing DSP reset makes no change to
BUSY port "L".
"□ＤＳＰ3 □ ＥＲＲＯＲ □１１□ "
No change to BUSY port "L" before issuing DSP special read command.
"□ＤＳＰ3 □ ＥＲＲＯＲ □１２□ "
No change to BUSY port "L" before DSP version read.
"□ＤＳＰ3 □ ＥＲＲＯＲ □１３□ "
y Both SUB/DSP
OK
(No error display, version display only)
