Denon AVR-X1800H User Manual

trqw e y
oiu
A
Power operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 67)
B
Power indicator
This is lit as follows according to the power status:
0
White: Power on
0
Off: Normal standby
0
Red:
0
When “HDMI Pass Through” is set to “On” (v p. 166)
0
When “HDMI Control” is set to “On” (v p. 168)
0
When “Network Control” is set to “Always On” (v p. 203)
C
SOURCE SELECT knob
This selects the input source. (v p. 67)
D
Remote control sensor
This receives signals from the remote control unit. (v p. 9)
E
Display
This displays various pieces of information. (v p. 19)
F
MASTER VOLUME knob
This adjusts the volume level. (v p. 68)
G
Tuner preset channel buttons
(TUNER PRESET CH +, –)
These select preset broadcast stations. (v p. 85)
H
ZONE2 ON/OFF button
This turns the power of ZONE2 (another room) on/off. (v p. 143)
I
ZONE2 SOURCE button
This selects the input source for ZONE2. (v p. 143)
Contents
Connections Playback Settings Tips Appendix
17
Front panel Display Rear panel Remote Index

Denon AVR-X1800H Specifications

General

Amplifier Channels	7.2
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Surround	Yes
DTS Neural:X	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS Multi-Room	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output per Channel	80W (8 ohms, 20Hz - 20kHz, 0.08% THD)
HDMI Inputs	6
HDR Support	HDR10+, Dolby Vision, HLG
Wi-Fi	Yes
Phono Input	Yes
Frequency Response	10Hz - 100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
