Denon AVR-X1800H User Manual

6
When the following screen is displayed, select “Begin
Test” and then press ENTER.
Start the measurement of the first position.
1
Audyssey Setup
Select "Begin Test" to start the calibration.
NOTE: You will hear a series of loud chirps starting and
stopping during the tests.
Do not stand or place any objects between the speakers
and microphone while the measurements are being
made.
Back
Begin Test
0
Measurement requires several minutes.
NOTE
0
If “ERROR” or “CAUTION” is displayed on TV screen:
0
Go to “Error messages” (v p. 187). Check any related items, and
perform the necessary procedures.
7
When the detected speaker is displayed, select “Next”
and then press ENTER.
Audyssey Setup
Speaker Detection
Front Yes
Yes
Yes
Yes
No
Center
Subwoofer
Surround
Surround Back
Repeat Last Test Next
Contents Connections Playback Settings Tips Appendix
183
Front panel Display Rear panel Remote Index

Denon AVR-X1800H Specifications

General

Amplifier Channels	7.2
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Surround	Yes
DTS Neural:X	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS Multi-Room	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output per Channel	80W (8 ohms, 20Hz - 20kHz, 0.08% THD)
HDMI Inputs	6
HDR Support	HDR10+, Dolby Vision, HLG
Wi-Fi	Yes
Phono Input	Yes
Frequency Response	10Hz - 100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
