Denon AVR-X1800H User Manual

o
Connecting the speaker cables
Carefully check the left (L) and right (R) channels and + (red) and –
(black) polarities on the speakers being connected to this unit, and be
sure to connect the channels and polarities correctly.
1
Peel off about 3/8 inch (10 mm) of sheathing from the
tip of the speaker cable, then either twist the core wire
tightly or terminate it.
2
Turn the speaker terminal counterclockwise to loosen it.
3
Insert the speaker cable’s core wire to the hilt into the
speaker terminal.
4
Turn the speaker terminal clockwise to tighten it.
o
Connecting the subwoofer
Use a subwoofer cable to connect the subwoofer. Two subwoofers can
be connected to this unit.
The same signal is output from the respective subwoofer terminals.
SW1SW2
Contents
Connections Playback Settings Tips Appendix
34
Front panel Display Rear panel Remote Index

Denon AVR-X1800H Specifications

General

Amplifier Channels	7.2
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Surround	Yes
DTS Neural:X	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS Multi-Room	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output per Channel	80W (8 ohms, 20Hz - 20kHz, 0.08% THD)
HDMI Inputs	6
HDR Support	HDR10+, Dolby Vision, HLG
Wi-Fi	Yes
Phono Input	Yes
Frequency Response	10Hz - 100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
