Denon AVR-X1800H User Manual

Connecting to a home network (LAN)
This unit can connect to a network using a wired LAN or wireless LAN.
You can connect this unit to your home network (LAN) to enable various
types of playback and operations as described below.
0
Playback of network audio such as Internet Radio and from your media
server(s)
0
Playback of streaming music services
0
Using the Apple AirPlay function
0
Operation on this unit via the network
0
Operation with the HEOS wireless multi-room sound system
0
Firmware Update
For connections to the Internet, contact an ISP (Internet Service
Provider) or a computer shop.
Wired LAN
To make connections via wired LAN, use a LAN cable to connect the
router to this unit as shown in the figure below.
Internet
Modem
PC
Router
To WAN side
To LAN port
To LAN port
NAS
(Network Attached
Storage)
LAN port /
Ethernet
connector
LAN port /
Ethernet
connector
Contents Connections Playback Settings Tips Appendix
62
Front panel Display Rear panel Remote Index

Denon AVR-X1800H Specifications

General

Amplifier Channels	7.2
HDMI Version	2.1
HDCP Support	2.3
eARC	Yes
Dolby Atmos	Yes
DTS:X	Yes
Dolby Surround	Yes
DTS Neural:X	Yes
Bluetooth	Yes
AirPlay 2	Yes
HEOS Multi-Room	Yes
Input Sensitivity/Impedance	200 mV / 47 kohms
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output per Channel	80W (8 ohms, 20Hz - 20kHz, 0.08% THD)
HDMI Inputs	6
HDR Support	HDR10+, Dolby Vision, HLG
Wi-Fi	Yes
Phono Input	Yes
Frequency Response	10Hz - 100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
