Denon AVR-X2300W User Manual

o
7.1-channel playback
System for 7.1-channel surround playback.
n
Example connections when using surround back speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers.
.
FL
SW C
SL
FR
SR
SBRSBL
0
Set “Assign Mode” to “Surround Back” in the menu. (v p. 193)
.
SBR SBL
SW FLFR C SR SL
0
When using a single surround back speaker, connect it to the SURROUND BACK
L terminal.
Contents Connections Playback Settings Tips Appendix
39
Front panel Display Rear panel Remote Index

Denon AVR-X2300W Specifications

General

Receiver type	-
Audio output channels	7.2 channels
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
Number of HDMI outputs	2
Wi-Fi	Yes
