Example connections when using front Dolby Atmos Enabled speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with front Dolby Atmos Enabled speakers.
.
C
SWFL FR
SL SR
FDL FDR
0
Set “Assign Mode” to “Front Dolby” in the menu. (v p. 193)
.
FDR FDL
SW FLFR C SR SL
Contents
Connections Playback Settings Tips Appendix
43
Front panel Display Rear panel Remote Index

Denon AVR-X2300W Specifications

General

Receiver type	-
Audio output channels	7.2 channels
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	7
Number of HDMI outputs	2
Wi-Fi	Yes
