Denon AVR-X2500H User Manual

Technical information
Number of power amp 7
Power output
150 W
(6 ohms, 1 kHz, 1% 1ch Drive)
125 W
(6 ohms, 1 kHz, 0.7% 2ch Drive)
95 watts per channel
(8 ohms, 20 Hz – 20 kHz, 0.08% 2ch Drive)
Speaker impedance 4 – 16 Ω / ohms
Preamplifier section
Input sensitivity/ impedance 200 mV / 47 kohms
Frequency response 10 Hz – 100 kHz — +1, –3 dB (Direct mode)
S/N Ratio 100 dB (IHF–A weighted, Direct mode)
FM section
Tuning frequency range 87.5 MHz – 108 MHz
AM section
Tuning frequency range 520 kHz – 1611 kHz
General
Power supply AC 230 V, 50 Hz
Power consumption 500 W
Power consumption No-Sound 35W / 75 W Eco On/Off
Dimensions (W x H x D 434 x 167 x 339 mm
Weight 9.4kg
EAN
AVRX2500HBKE2 4951035065174 Black
AVRX2500HBKE2GB 4951035066409 Black

Denon AVR-X2500H Specifications

General

HDMI in	8
Composite video in	2
Ethernet LAN (RJ-45) ports	1
AirPlay	No
Display	-
Sample rate	196 kHz
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS-HD, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
RS-232 interface	Yes
Connectivity technology	Wired & Wireless
Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
Supported graphics resolutions	3840 x 2160

Weight and Dimensions

Depth	340.3 mm
Width	434.3 mm
Height	167.6 mm
Weight	9389 g
