Denon AVR-X2500H User Manual

0
The two special adjustment modes, “ISF Day” and “ISF Night”, should be used
by a certified technician to adjust the color calibration to match the installation
conditions.
We recommend that the settings and adjustments be carried out by an ISF-
certified technician.
0
These settings can also be configured using “Picture Mode” in the option
menu. (v p. 158)
o
Contrast
Adjust picture contrast.
-50 – +50 (Default : 0)
o
Brightness
Adjust picture brightness.
-50 – +50 (Default : 0)
o
Saturation
Adjust picture chroma level (color saturation).
-50 – +50 (Default : 0)
o
Noise Reduction
Reduce overall video noise.
Low / Medium / High / Off (Default : Off)
o
Enhancer
Emphasize picture sharpness.
0 – +12 (Default : 0)
Contents Connections Playback Settings Tips Appendix
159
Front panel Display Rear panel Remote Index

Denon AVR-X2500H Specifications

General

HDMI in	8
Composite video in	2
Ethernet LAN (RJ-45) ports	1
AirPlay	No
Display	-
Sample rate	196 kHz
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS-HD, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
RS-232 interface	Yes
Connectivity technology	Wired & Wireless
Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
Supported graphics resolutions	3840 x 2160

Weight and Dimensions

Depth	340.3 mm
Width	434.3 mm
Height	167.6 mm
Weight	9389 g
