Page #237 background image
Cannot connect to a wireless LAN network
Cannot connect to the network.
0
The network name (SSID), password and encryption setting have not been set up correctly. Configure the network settings according to the setting
details of this unit. (v p. 198)
0
Shorten the distance from the wireless LAN access point and remove any obstructions to improve access first before re-connecting again. Place the
unit away from microwave ovens and other network access points.
0
Configure the access point channel settings away from channels that are being used by other networks.
0
This unit is not compatible with WEP (TSN).
Cannot connect to a WPS Router.
0
Check that the WPS mode of the router is operating.
0
Press the WPS button on the router and then press the “Connect” button displayed on the TV within 2 minutes.
0
A router/settings that are compatible with WPS 2.0 standards are required. Set the encryption time to “None”, “WPA-PSK (AES)” or WPA2-PSK (AES).
(v
p. 198)
0
If the router encryption method is WEP/WPA-TKIP/WPA2-TKIP, you cannot connect by using the WPS button on the router. In this case, use the “Scan
Networks” or “Manual” method to connect.
Cannot connect to the network using iPhone/iPod touch/iPad.
0
Update the iPhone/iPod touch/iPad firmware to the latest version.
0
When configuring the settings via a wireless connection, iOS 7 or later needs to be supported.
Contents
Connections Playback Settings Tips Appendix
237
Front panel Display Rear panel Remote Index

Other manuals for Denon AVR-X2500H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X2500H and is the answer not in the manual?

Denon AVR-X2500H Specifications

General IconGeneral
HDMI in8
Composite video in2
Ethernet LAN (RJ-45) ports1
AirPlayNo
Display-
Sample rate196 kHz
HDCP version2.2
Product colorBlack
Audio decodersDSD, DTS-HD, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume controlRotary
RS-232 interfaceYes
Connectivity technologyWired & Wireless
Receiver typeSurround
Frequency range20 - 20000 Hz
Output impedance8 Ω
Input sensitivity200 mV
Audio output channels7.1 channels
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.08 %
Power output per channel (1KHz@6 Ohm)185 W
Power output per channel (20-20KHz@8 Ohm)95 W
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.5 W
Power consumption (typical)500 W
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range520 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Internet radio services supportedDeezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
Supported graphics resolutions3840 x 2160
Weight and Dimensions IconWeight and Dimensions
Depth340.3 mm
Width434.3 mm
Height167.6 mm
Weight9389 g
